Fundamental Parameter

The fundamental parameter of the main circuit

• Rated insulation voltage 660V
• Rated working current 25、35、93A separately
• The regulator seal of rated setting current
• Current of the thermal component

Auxiliary Circuit

• There is one pair of N/O and N/C contact with electric insulation
• Rated insulation voltage 550V
• Rated frequency 50-60Hz
• Use group, rated working voltage, conventional thermal current, and rated current

Data Sheet
